Sometimes one chart just isn’t good enough. Sometimes you need more.

Perhaps the story you are telling with your visualization needs to be told from different perspectives and different charts cull out these different angles nicely. Maybe, you need to support different types of users and different plots appeal to these separate sets. Or maybe you just want to add a bit of flare to your visualization with a chart toggle.

In any case, done right, transitioning between multiple chart types in the same visualization can add more insights and depth to the experience. Smooth, animated transitions make it easier for the user to follow what is changing and how the data presented in different formats relates to one another.

This tutorial will use D3.js and its built in transitioning capabilities to nicely contort our data into a variety of graph types.

If you're a FlowingData member, you might be familiar with creating these chart types in R.We will focus on visualizing time series data and will allow for transitioning between 3 types of charts: Area Chart, Stacked Area Chart, and Streamgraph. The data being visualized will be New York City 311 request calls around the time hurricane Sandy hit the area.

Check out the demo to see what we will be creating, then download the source code and follow along!

The Setup

Before we dive in, let’s take a look at the ingredients that will go into making this visualization.

D3 v3

Recently, the third major version of D3.js was released: d3.v3.js. Updates include tweaks and improvements to how transitions work, making them easier overall to use.

If you have used D3.js previously, one significant change you will want to know about is that the signature of the callback function for loading data has changed. Specifically, when you load data, you now get passed any errors that have occurred during the data request first, and then the actual data array. So this:

d3.json('data', (data) -> console.log(data.length))

Becomes this:

d3.json('data', (error, data) -> console.log(data.length))

Not a huge deal, as the old API is still supported (though deprecated), but one that gives you enough advantages that you should start using it.

For More on D3.v3, check out the 3.0 upgrading guide on the D3.js wiki.

A Big Cup of CoffeeScript

And again, please feel free to compile to javascript if that will make you happy. But before you do, give CoffeeScript 5 minutes of your time – who knows, you just might fall in love.As in my previous tutorial on interactive networks , I’ll be writing the code in CoffeeScript . I recommend going back to that tutorial if you aren’t familiar with CoffeeScript to get some notes on its syntax. But just in case you don’t want to click that link, here’s the 3 second version:

functions look like this:

functionName = (input1, input2) ->
  console.log('hey! I'm a function')

We see that white space matters – the indentation indicates the lines of code inside a function, loop, or conditional statement. Also, semicolons are left off, and parentheses are sometimes optional, though I usually leave them in.

A Little Python Web Server

The README in the source code also has instructions for using Ruby.Because of how D3.js loads data, we need to run it from a web server, even when developing on our own local machine. There are lots of web servers out there, but probably the easiest to use for our development purposes is Python’s built in Simple Server.

From the Terminal, first navigate to the source code directory for this tutorial. Then check which version of Python you have installed using:

python --version

If it is Python 3.x then use this line to start the server:

python -m http.server

If it is Python 2.x then use

python -m SimpleHTTPServer

In either case, you should have a basic web server that can serve up any file from the directory you are in to your web browser, just by navigating to http://0.0.0.0:8000.

The simple python web server running on my machine

But What About Windows

On Linux or Mac systems, you will already have python installed. However, it takes some moxie to get it working on a Windows machine. I would suggest looking over this blog post, to make sure you don't overlook something.

If you aren't in the mood for some python wrangling, you might take the advice of this getting started with D3 guide and try out EasyPHP. With this installed and running, you can host your D3 projects out of the www/ directory in the root of the installation location.

A Dash of Bootstrap

While we will use D3.js for the actual visualization implementation, we will take advantage of Twitter’s Bootstrap framework to make our vis just a bit more attractive.

Mostly, it will be used to make a nice toggle button that will used to transition between charts. This might not be the most efficient method for getting a decent looking toggle on a site, but it is very easy to implement and will give you a chance to check out Bootstrap, if you haven’t already. It is quite lovely.

Transitions

Before we start using them, lets talk a bit about what D3 transitions are and how they work.

Think of a transition as an animation. The staring point of this animation is the current state of whatever you are transitioning. Its position, color, etc. When creating a new transition, we tell it what the elements should end up looking like. D3 fills in the gap from the current state to the final one.

D3 is built around working with selections. Selections are arrays of elements that you work with as a group. For example, this code selects all the circle elements in the SVG and colors them red:

svg.selectAll("circle")
  .attr("fill", "red")

It might then come as little surprise that transitions in D3 are a special kind of selection, meaning you can effect a group of multiple elements on a page concisely within a single transition. This is great because if you are already familiar with selections, then you already know how to create and work with transitions.

There are a few more differences between selections and transitions – mainly due to the fact that some element attributes cannot be animated.The main difference between regular selections and transitions is that selections modify the appearance of the elements they contain immediately. As soon as the .attr("fill", "red") code is executed, those circles become red. Transitions, on the other hand, smoothly modify the appearance over time.

Here is an example of a transition that changes the position and color of the circles in a SVG:

# First we set an initial position and color for these circles.
# This is NOT a transition
svg.selectAll("circle")
  .attr("fill", "red")
  .attr("cx", 40)
  .attr("cy", height / 2)

# Here is the transition that changes the circles
# position and color.
svg.selectAll("circle")
  .transition()
  .delay(500)
  .duration(750)
  .attr("fill", "green")
  .attr("cx", 500)
  .attr("cy", (d, i) -> 100 * (i + 1))

I’ve coded up a live version of this demo (in JavaScript), to get a better feel for what is going on.

The functions called on the transition can be separated into 2 groups: those modifying the transition itself, and those indicating what the appearance of the selected elements should be when the transition completes.

The delay() and duration() functions are in the former category. They indicate how long to wait to start the transition, and how long the transition will take.

The attr() calls on the transition are in the later category. They indicate that once the animation is done, the circles should be green, and they should be in new positions. As you can see from the live example, D3 does the hard work of interpolating between starting and ending appearance in the duration you’ve provided.

There are lots of interesting details you can learn about transitions. For a more through introduction, I’d recommend Jerome Cukier’s introduction on visual.ly.

Custom interpolation, start and end triggers, transition life cycles, and more await you in this great guide!To really rip off the covers, check out Mike Bostock’s Transitions Guide , which exposes more of the nitty gritty details of transitions and is required reading once you start needing their more advanced capabilities.

For now, let’s stop with the prep work and get going on more of the specifics of how this visualization works.

A Peak at the Data

When I discovered the NYC OpenData site provided access to raw 311 service request data, I had visions of recreating the classic 311 streamgraph from Wired Magazine originally created by Pitch Interactive.

Alas, my dreams were dashed upon the realization that the times reported for all the requests was set to midnight! I assume some sort of bug in the export process is currently preventing the time from being encoded correctly.

Not wanting to give up on this interesting dataset, I decided to switch gears and instead look at daily aggregation of requests during an interesting period of recent New York history: hurricane Sandy. This tells, I think, an interesting, if not surprising, story. Priorities change when a natural disaster strikes.

Here is what the data looks like:

[
  {
    "key": "Heating",
    "values": [
      {
        "date": "10/14/12",
        "count": 428
      },
      {
        "date": "10/15/12",
        "count": 298
      },
      // ...
    ]
  },
  {
    "key": "Damaged tree",
    "values": [
      // ...
    ]
  },
  // ...
]

In words, our array of data is organized by 311 request type. Each request object has a key string and then an array called values. Values has an entry for each day in the visualization. Each day object has a string representation of the date as well as the number of this type of request for that day, stored in count.

You could use d3.nest to convert a simple table into a similar array of objects, but that is a tutorial for another day.This format was chosen to match up with how the visualization will be built. As we will see, the root-level request objects will be represented as SVG groups. Inside each group, the values array will be converted into line and area paths.

A Static Starting Point

To create movement, one must begin with stillness. How’s that for sage advice? Not great? Well, it will work well enough for us in this tutorial.

Transitions don’t deal with the creation of new elements. An element needs to exist already in order to be animated. So to begin our visualization, we will create a starting point from which the visualization can transition from.

Layouts and Generators

First let’s setup the generators and layout we will use to create the visualization. We will be using an area generator to create the areas of each chart, a line generator for the detail on the regular area chart, and the stack layout for the streamgraph and stacked area chart, as well as some scales for x, y, and color.

Here is what the initialization code looks like:

x = d3.time.scale()
  .range([0, width])

y = d3.scale.linear()
  .range([height, 0])

color = d3.scale.category10()

# area generator to create the
# polygons that make up the
# charts
area = d3.svg.area()
    .interpolate("basis")
    .x((d) -> x(d.date))

# line generator to be used
# for the Area Chart edges
line = d3.svg.line()
    .interpolate("basis")
    .x((d) -> x(d.date))

# stack layout for streamgraph
# and stacked area chart
stack = d3.layout.stack()
  .values((d) -> d.values)
  .x((d) -> d.date)
  .y((d) -> d.count)
  .out((d,y0,y) -> d.count0 = y0)
  .order("reverse")

The stack layout could use a bit more explanation.

Unlike what its name might imply, this layout doesn’t actually move any elements itself – that would be very un-D3 like. Instead, its main purpose in this visualization is to calculate the location of the baseline – which is to say the bottom – of the area paths. It computes the baseline for all the elements in the values array based on the stack’s offset() algorithm.

The out() function allows us to see this calculated baseline value and capture it in an attribute of our value objects. In the code above, we assign count0 to this baseline value. After the stack is executed on a set of data, we will be able to use count0 along with the area generator to create areas in the right location.

Loading the Data

Ok, we need to load the JSON file that contains all our data.

This is done in D3 by using d3.json:

$ ->
  d3.json("data/requests.json", display)

Load the requests.json file, then call the display function with the results.

Here is display:

display = (error, rawData) ->
  # a quick way to manually select which calls to display.
  # feel free to pick other keys and explore the less frequent call types.
  filterer = {"Heating": 1, "Damaged tree": 1, "Noise": 1, "Traffic signal condition": 1, "General construction":1, "Street light condition":1}

  data = rawData.filter((d) -> filterer[d.key] == 1)

  # a parser to convert our date string into a JS time object.
  parseTime = d3.time.format.utc("%x").parse

  # go through each data entry and set its
  # date and count property
  data.forEach (s) ->
    s.values.forEach (d) ->
      d.date = parseTime(d.date)
      d.count = parseFloat(d.count)

    # precompute the largest count value for each request type
    s.maxCount = d3.max(s.values, (d) -> d.count)

  data.sort((a,b) -> b.maxCount - a.maxCount)

  start()

The requests.json file has data for every request type, which would overload our visualization. Here we perform a basic filter to cherry pick some interesting types.

d3.time.format and the other time formatting capabilities of D3.js are great for converting strings into JavaScript Date objects. Here, our parser is expecting a date string in the %m/%d/%y format (which is what %x is shorthand for. We use this formatter when we iterate through the raw data to convert each string into a date and save it back in the object.

Then we call start() to get the display ball rolling.

The Start of the Visualization

Finally, we are ready to create the elements needed to get our charts going. Here is the start() function which sets up these elements:

start = () ->
  # x domain setup
  minDate = d3.min(data, (d) -> d.values[0].date)
  maxDate = d3.max(data, (d) -> d.values[d.values.length - 1].date)
  x.domain([minDate, maxDate])

  # I want the starting chart to emanate from the
  # middle of the display.
  area.y0(height / 2)
    .y1(height / 2)

  # now we bind our data to create
  # a new group for each request type
  g = svg.selectAll(".request")
    .data(data)
    .enter()

  requests = g.append("g")
    .attr("class", "request")

  # add some paths that will
  # be used to display the lines and
  # areas that make up the charts
  requests.append("path")
    .attr("class", "area")
    .style("fill", (d) -> color(d.key))
    .attr("d", (d) -> area(d.values))

  requests.append("path")
    .attr("class", "line")
    .style("stroke-opacity", 1e-6)

  # default to streamgraph display
  streamgraph()

We still haven’t drawn anything, but we are getting close.

The data array is bound to the empty .request selection. Then, as mentioned in the data section above, a g element is created for each request type.

Finally, two path elements are appended to the group. One of which is for drawing the areas of the three charts. The other, with the class .line, will be used to draw lines in the regular area chart.

Without this, the first transition will just cause the areas to appear immediately.
As a little detail, I’ve started the .area paths in the center of the display, so the first transition to the first chart will grow out from the center.

A Movement in Three Parts

Now that we have the basic visualization framework, we can focus on developing the code for each chart.

We want the user to be able to switch back and forth between all the graph styles, in a non-linear manner. To accomplish this, the functions implementing each chart needs to accomplish 3 things:

1. Recompute values that might get changed by switching to the other charts.
2. Reset shared layouts and scales to handle the selected chart.
3. Create a new transition on the elements making up each chart.

With this consistent structure in mind, let’s start coding up some charts.

Steamgraph

The initial streamgraph display

We will start with the streamgraph – because of my original dreams to emulate Wired, and because it is pretty easy to create with the stack layout.

streamgraph = () ->
  # 'wiggle' is streamgraph offset
  stack.offset("wiggle")
  stack(data)

  # reset our y domain and range so that it
  # accommodates the highest value + offset
  y.domain([0, d3.max(data[0].values.map((d) -> d.count0 + d.count))])
    .range([height, 0])

  # setup the area generator to utilize
  # the count0 values created from the layout
  area.y0((d) -> y(d.count0))
    .y1((d) -> y(d.count0 + d.count))

  # here we create the transition
  t = svg.selectAll(".request")
    .transition()
    .duration(duration)

  # D3 will take care of the details of transitioning
  t.select("path.area")
    .style("fill-opacity", 1.0)
    .attr("d", (d) -> area(d.values))

Its all a bit anticlimactic, right? The shape of the path is defined by the attribute d. See the MDN tutorial if you aren’t familiar with SVG paths.Look at that. We didn’t even have to get our hands dirty with creating SVG paths. The area generator did it all for us. Nor did we have to deal with any of the animation from current state to final streamgraph. The transition helped us out there. So what did we do?

The initial call to stack(data) causes the stack layout to run on our data. Its setup to use wiggle as the offset, which is the offset to use for streamgraphs.

The y scale needs to be updated to ensure the tallest ‘stream’ is accounted for in its calculation.

Again, check out that Transition Guide for more clarity on how this works.The last section of the streamgraph function is the transition. We create a new transition selection on the .request groups. Then we select the .area path’s inside each group and set the path and opacity they should end up using the attr() calls.

D3 will interpolate the path’s values smoothly over the duration of the transition to end up at a nice looking streamgraph for our data. The great thing is that this same code will work for transitioning from the initial blank display as well as from the other chart types!

Stacked Area Chart

The stacked area chart provides a new view with little code.

I’m not going to go over the code for the stacked area chart – as it is near identical to the streamgraph.

The only real difference is that the offset used for the stack layout calculations is switched from wiggle to zero. This modifies the count0 values when the stack is executed on the data, which then adjusts the area paths to be stacked instead of streamed.

Area Chart

With the overlapping area chart, we reduce opacity to prevent from obscuring ‘short’ areas

Our last chart is a basic overlapping area chart. This one is a little different, as we won’t need to use the stack layout for area positioning. Also, we will finally get to use that .line path we created during the setup.

Here is the relevant code for this chart:

areas = () ->
  g = svg.selectAll(".request")

  # as there is no stacking in this chart, the maximum
  # value of the input domain is simply the maximum count value,
  # which we precomputed in the display function
  y.domain([0, d3.max(data.map((d) -> d.maxCount))])
    .range([height, 0])

  # the baseline of this chart will always
  # be at the bottom of the display, so we
  # can set y0 to a constant.
  area.y0(height)
    .y1((d) -> y(d.count))

  line.y((d) -> y(d.count))

  t = g.transition()
    .duration(duration)

  # partially transparent areas
  t.select("path.area")
    .style("fill-opacity", 0.5)
    .attr("d", (d) -> area(d.values))

  # show the line
  t.select("path.line")
    .style("stroke-opacity", 1)
    .attr("d", (d) -> line(d.values))

The main difference between this chart and the previous two is that we are not using the count0 values in any of the area layouts. Instead, the bottom line of the areas is set to the height of the visualization, so it will always stay at the bottom of the display.

The .line is adjusted in the other charts too (just not shown in these snippets). It is just always set to be invisible in the transition.In the transition, we set the opacity of the area paths to be 0.5 so that all the areas are still visible. Then we do another selection to set the .line path so that it appears as the top outline of our areas.

Switching Back and Forth

As each of these charts is contained in its own function, transitioning between charts becomes as easy as just executing the right function.

Here is the code that does just that when the toggle button is pushed:

transitionTo = (name) ->
  if name == "stream"
    streamgraph()
  if name == "stack"
    stackedAreas()
  if name == "area"
    areas()

Each of these functions creates and starts a new transition, meaning switching to a new chart will halt any transition currently running, and then immediately start the new transition from the current element locations.

The Little Details

There are some finishing touches that I’ve made to the visualization that I won’t go into too much depth on. D3’s axis component was used to create the background lines marking every other day.

Shameless plug: Check out my tutorial on small multiples if you want to take a deeper look into the implementation of this great pieceA little legend, inspired by the legend in the Manifest Destiny visualization. It is also an SVG element and the mouseover event causes a transition that shifts the key into view. The details are in the code.

Finally, like I mentioned above, the toggle button to switch between charts was created using bootstrap. Checkout the button documentation for the details.

Wrapping Up

Well hopefully now you have a better grasp on using transitions to switch between different displays for your data. We can really see the power of D3 in how little code it takes to create these different charts and interactively move between them.

Thanks again to Mike Bostock, the creator of D3. His presentation on flexible transitions served as the main inspiration for this tutorial.

Now get out there and start transitioning! Let me know when you create your own face melting (and functional) animations.

Networks! They are all around us. The universe is filled with systems and structures that can be organized as networks. Recently, we have seen them used to convict criminals, visualize friendships, and even to describe cereal ingredient combinations. We can understand their power to describe our complex world from Manuel Lima's wonderful talk on organized complexity. Now let's learn how to create our own.

In this tutorial, we will focus on creating an interactive network visualization that will allow us to get details about the nodes in the network, rearrange the network into different layouts, and sort, filter, and search through our data.

In this example, each node is a song. The nodes are sized based on popularity, and colored by artist. Links indicate two songs are similar to one another.

Try out the visualization on different songs to see how the different layouts and filters look with the different graphs.

Technology

This visualization is a JavaScript based web application written using the powerful D3 visualization library. jQuery is also used for some DOM element manipulation. Both frameworks are included in the js/libs directory of the source code.

If you hate CoffeeScript, you can always compile the code to JavaScript and start there.The code itself is actually written in CoffeeScript, a little language that is easy to learn, and compiles down to regular JavaScript. Why use CoffeeScript? I find that the reduced syntax makes it easier to read and understand what the code is doing. While it may seem a bit intimidating to learn a whole new 'language', there are just a few things you need to know about CoffeeScript to be a pro.

Quick CoffeeScript Notes

Functions

First and foremost, This is what a function looks like:

functionName = (input) ->
  results = input * 2
  results

So the input parameters are inside the parentheses. The -> indicates the start of the implementation. If a function's implementation is super simple, this can all go on one line.

cube = (x) -> x * x * x

A function returns the last thing executed, so you typically don't need a return statement, but you can use one if you like.

Indentation matters

The other main syntactical surprise is that, similar to Python, indentation is significant and used to denote code hierarchy and scope. We can see an example of this in the function above: The implementation is indented.

In practice, this isn't too big of an issue: just hit the Tab key instead of using curly braces – {, } – and you are set.

Semicolons and Parentheses

Taking a page from Ruby, semicolons are not needed and should be avoided in CoffeeScript.

Also, parentheses are optional in many places. While this can get confusing, I typically use parentheses unless they are around a multi-line function that is an input argument into another function. If that doesn't make sense, don't worry – the code below should still be easy to follow.

For other interesting details, spend a few minutes with the CoffeeScript documentation. You won't be disappointed.

In-browser CoffeeScript

Using CoffeeScript is made simpler by the fact that our CoffeeScript code can be compiled into JavaScript right in the browser. Our index.html includes the CoffeeScript compiler which in turn compiles to JavaScript any script listed as text/coffeescript :

<script src="js/libs/coffee-script.js"></script>
<script type="text/coffeescript" src="coffee/vis.coffee"></script>

It's just that simple. When vis.coffee loads, it will be parsed and compiled into JavaScript before running. For production, we would want to do this compilation beforehand, but this let's us get started right away.

Setting up the Network

You don't have to organize your code like this, if it seems like too much work. But the encapsulation makes it easier to change your input data laterOk, let's get started with coding this visualization. We are going to be using a simplified version of Mike Bostock's (the creator of D3) reusable chart recommendations to package our implementation. What this means for us is that our main network code will be encapsulated in a function, with getters and setters to allow interaction with the code from outside. Here is the general framework:

Network = () ->
  width = 960
  height = 800
  # ...
  network = (selection, data) ->
    # main implementation

  update = () ->
    # private function

  network.toggleLayout = (newLayout) ->
    # public function

  return network

So the Network function defines a closure which scopes all the variables used in the visualization, like width and height. The network function is where the main body of the code goes, and is returned by Network at the end of the implementation.

Functions defined on network, like network.toggleLayout() can be called externally while functions like update are 'private' functions and can only be called by other functions inside Network. You can think of it as the same abstraction that classes provide us in object-oriented programing. Here is how we create a new network :

$ ->
  myNetwork = Network()
  # ...

  d3.json "data/songs.json", (json) ->
    myNetwork("#vis", json)

So here, myNetwork is the value Network() returns – namely the function called network. Then we call this network function, passing in the id of the div where the visualization will live, and the data to visualize.

Network Data Format

From above, we see we are passing in the data from songs.json to be visualized. How is this data organized?

Since a network defines connections between nodes as well as the data contained in the nodes themselves, it would be difficult to define as a simple 'spreadsheet' or table of values. Instead, we use JSON to capture this structure with as little overhead as possible.

The input data for this visualization is expected to follow this basic structure:</p

{
  "nodes": [
    {
      "name": "node 1",
      "artist": "artist name",
      "id": "unique_id_1",
      "playcount": 123
    },
    {
      "name": "node 2",
      # ...
    }
  ],
  "links": [
    {
      "source": "unique_id_1",
      "target": "unique_id_2"
    },
    {
      # ...
    }
  ]
}

This is a JSON object (just like a JavaScript object). If you haven't looked at JSON before, then let's take a look now! The format is pretty straight forward (as it's just JavaScript).

This object requires two names, nodes and links. Both of these store arrays of other objects. nodes is an array of nodes. Each node object needs some fields used in the visualization as well as an id which uniquely identifies that node.

The objects in the links array just need source and target. Both of these point to @id@'s of nodes.

The traditional/default method in D3 of defining a link's source and target is to use their position in the nodes array as the value. Since we are going to be filtering and rearranging these nodes, I thought it would be best to use values independent of where the nodes are stored. We will see how to use these id's in a bit.

Moved by the Force

We will start with the default force-directed layout that is built into D3 . Force-based network layouts are essentially little physics simulations. Each node has a force associated with it (hence the name), which can repel (or attract) other nodes. Links between nodes act like springs to draw them back together. These pushing and pulling forces work on the network over a number of iterations, and eventually the system finds an equilibrium.

Force-directed layouts usually result in pretty good looking network visualizations, which is why they are so popular. D3's implementation does a lot of work to make the physics simulation efficient, so it stays fast in the browser.

Example of force-directed layout from our song network demo

To start, as is typical with most D3 visualizations, we need to create a svg element in our page to render to. Lets look at the network() function which performs this action:

First we declare a bunch of variables that will be available to us inside the Network closure. They are 'global' and available anywhere in Network. Note that our D3 force directed layout is one such global variable called force.

Inside our network function, we start by tweaking the input data. Then we use D3 to append an svg element to the input selection element. linksG and nodesG are group elements that will contain the individual lines and circles used to create the links and nodes. Grouping related elements is a pretty common strategy when using D3. Here, we create the linksG before the nodesG because we want the nodes to sit on top of the links.

The update function is where most of the action happens, so let's look at it now.

  # The update() function performs the bulk of the
  # work to setup our visualization based on the
  # current layout/sort/filter.
  #
  # update() is called everytime a parameter changes
  # and the network needs to be reset.
  update = () ->
    # filter data to show based on current filter settings.
    curNodesData = filterNodes(allData.nodes)
    curLinksData = filterLinks(allData.links, curNodesData)

    # sort nodes based on current sort and update centers for
    # radial layout
    if layout == "radial"
      artists = sortedArtists(curNodesData, curLinksData)
      updateCenters(artists)

    # reset nodes in force layout
    force.nodes(curNodesData)

    # enter / exit for nodes
    updateNodes()

    # always show links in force layout
    if layout == "force"
      force.links(curLinksData)
      updateLinks()
    else
      # reset links so they do not interfere with
      # other layouts. updateLinks() will be called when
      # force is done animating.
      force.links([])
      # if present, remove them from svg
      if link
        link.data([]).exit().remove()
        link = null

    # start me up!
    force.start()

The final version of this visualization will have filtering and sorting capabilities, so update starts with filtering the nodes and links of the total dataset. Then sorts if necessary. We will come back and hit these functions later. For the basic force-directed layout without all these bells and whistles to come, all we really care about is:

force.nodes(curNodesData)
updateNodes()

force.links(curLinksData)
updateLinks()

The force's nodes array is set to our currently displayed nodes, erasing any previous nodes in the simulation. Then we update the visual display of the nodes in the visualization. This same pattern is then followed for the links.

Remember: the force layout doesn't add circles and lines for you. It just tells you where to put them.It is important to realize that in D3, the nodes and links in the force layout don't automatically get visualized in any way. This is to say that there is a separation between the force-directed physics simulation and any visual mapped to that simulation.

To create this visual representation associated with this force-directed simulation, we will need to bind to the same data being used, which we do in updateNodes and updateLinks:

  # enter/exit display for nodes
  updateNodes = () ->
    node = nodesG.selectAll("circle.node")
      .data(curNodesData, (d) -> d.id)

    node.enter().append("circle")
      .attr("class", "node")
      .attr("cx", (d) -> d.x)
      .attr("cy", (d) -> d.y)
      .attr("r", (d) -> d.radius)
      .style("fill", (d) -> nodeColors(d.artist))
      .style("stroke", (d) -> strokeFor(d))
      .style("stroke-width", 1.0)

    node.on("mouseover", showDetails)
      .on("mouseout", hideDetails)

    node.exit().remove()

  # enter/exit display for links
  updateLinks = () ->
    link = linksG.selectAll("line.link")
      .data(curLinksData, (d) -> "#{d.source.id}_#{d.target.id}")
    link.enter().append("line")
      .attr("class", "link")
      .attr("stroke", "#ddd")
      .attr("stroke-opacity", 0.8)
      .attr("x1", (d) -> d.source.x)
      .attr("y1", (d) -> d.source.y)
      .attr("x2", (d) -> d.target.x)
      .attr("y2", (d) -> d.target.y)

    link.exit().remove()

Finally, some D3 visualization code! Looking at updateNodes, we select all circle.node elements in our nodeG group (which at the very start of the execution of this code, will be empty). Then we bind our filtered node data to this selection, using the data function and indicating that data should be identified by its id value.

The enter() function provides an access point to every element in our data array that does not have a circle associated with it. When append is called on this selection, it creates a new circle element for each of these representation-less data points. The attr and style functions set values for each one of these newly formed circles. When a function is used as the second parameter, like:

.attr("r", (d) -> d.radius)

The d is the data associated with the visual element, which is passed in automatically by D3. So with just a few lines of code we create and style all the circles we need.

Because we will be filtering our data to add and remove nodes, there will be times where there is a circle element that exists on screen, but there is no data behind it. This is where the exit() function comes into play. exit() provides a selection of elements which are no longer associated with data. Here we simply remove them using the remove function.

If the concepts of enter() and exit() are still not clicking, check out the Thinking With Joins and three little circles tutorials. These selections are a big part of D3, so it is worth having a feel for what they do.

Configuring the Force

There has to be a ton of Star Wars jokes I should be making... but I can't think of any.In order to get the force-directed graph working the way we want, we need to configure the force layout a bit more. This will occur in the setLayout function. For the force-directed layout, our force configuration is pretty simple:

force.on("tick", forceTick)
.charge(-200)
.linkDistance(50)

Here, charge is the repulsion value for nodes pushing away from one another and linkDistance is the maximum length of each link. These values allow the nodes to spread out a bit.

The forceTick function will be called each iteration (aka 'tick') of the simulation. This is where we need to move our visual representations of the nodes and links of the network to where they are in the simulation after this tick. Here is forceTick:

  # tick function for force directed layout
  forceTick = (e) ->
    node
      .attr("cx", (d) -> d.x)
      .attr("cy", (d) -> d.y)

    link
      .attr("x1", (d) -> d.source.x)
      .attr("y1", (d) -> d.source.y)
      .attr("x2", (d) -> d.target.x)
      .attr("y2", (d) -> d.target.y)

Pretty straightforward. The D3 simulation is modifying the x and y values of each node during the simulation. Thus, for each tick, we simply need to move the circles representing our nodes to where x and y are. The links can be moved based on where their source and target nodes are.

Setting Up Data

Speaking of source and target, we need to go back and see how to deal with our initial data where we were using the id of a node in place of the node's index in the nodes array. Here is setupData which is the very first thing executed in our network code:

  # called once to clean up raw data and switch links to
  # point to node instances
  # Returns modified data
  setupData = (data) ->
    # initialize circle radius scale
    countExtent = d3.extent(data.nodes, (d) -> d.playcount)
    circleRadius = d3.scale.sqrt().range([3, 12]).domain(countExtent)

    data.nodes.forEach (n) ->
      # set initial x/y to values within the width/height
      # of the visualization
      n.x = randomnumber=Math.floor(Math.random()*width)
      n.y = randomnumber=Math.floor(Math.random()*height)
      # add radius to the node so we can use it later
      n.radius = circleRadius(n.playcount)

    # id's -> node objects
    nodesMap  = mapNodes(data.nodes)

    # switch links to point to node objects instead of id's
    data.links.forEach (l) ->
      l.source = nodesMap.get(l.source)
      l.target = nodesMap.get(l.target)

      # linkedByIndex is used for link sorting
      linkedByIndex["#{l.source.id},#{l.target.id}"] = 1

    data

setupData is doing a few things for us, so let's go through it all. First, we are using a d3.scale to specify the possible values that the circle radii can take, based on the extent of the playcount values. Then we iterate through all the nodes, setting their radius values, as well as setting their x and y values to be within the current visualization size. Importantly, nodes are not automatically sized by any particular data value they contain. We are just adding radius to our data so we can pull it out in updateNodes. The x and y initialization is just to reduce the time it takes for the force-directed layout to settle down.

Finally, we map node id's to node objects and then replace the source and target in our links with the node objects themselves, instead of the id's that were in the raw data. This allows D3's force layout to work correctly, and makes it possible to add/remove nodes without worrying about getting our nodes array and links array out of order.

Radializing the Force

Now we have everything needed to display our network in a nice looking, fast, force-directed layout. It might have been a lot of explanation, but we did it in a pretty small amount of code.

The force-directed layout is a great start, but also a bit limiting. Sometimes you want to see your network in a different layout – to find patterns or trends that aren't readily apparent in a force-directed one. In fact, it would be really cool if we could toggle between different layouts easily – and allow our users to see the data in a number of different formats. So, lets do that!

Here's a basic idea: we are going to hijack D3's force-directed layout and tell it where we want the nodes to end up. This way, D3 will still take care of all the physics and animations behind the scenes to make the transitions between layouts look good without too much work. But we will get to influence where the nodes go, so their movements will no longer be purely based on the underlying simulation.

Radial layout example, grouping song nodes by artist

Always force-jack with extreme cautionTo aid in our force-jacking, I've created a separate entity to help position our nodes in a circular fashion called RadialPlacement. Its not really a full-on layout, but just tries to encapsulate the complexity of placing groups of nodes. Essentially, we will provide it with an array of keys. It will calculate radial locations for each of these keys. Then we can use these locations to position our nodes in a circular fashion (assuming we can match up our nodes with one of the input keys).

RadialPlacement is a little clumsy looking, but gets the job done. The bulk of the work occurs in setKeys and radialLocation :

# Help with the placement of nodes
RadialPlacement = () ->
  # stores the key -> location values
  values = d3.map()
  # how much to separate each location by
  increment = 20
  # how large to make the layout
  radius = 200
  # where the center of the layout should be
  center = {"x":0, "y":0}
  # what angle to start at
  start = -120
  current = start

  # Given a set of keys, perform some
  # magic to create a two ringed radial layout.
  # Expects radius, increment, and center to be set.
  # If there are a small number of keys, just make
  # one circle.
  setKeys = (keys) ->
    # start with an empty values
    values = d3.map()

    # number of keys to go in first circle
    firstCircleCount = 360 / increment

    # if we don't have enough keys, modify increment
    # so that they all fit in one circle
    if keys.length < firstCircleCount       increment = 360 / keys.length     # set locations for inner circle     firstCircleKeys = keys.slice(0,firstCircleCount)     firstCircleKeys.forEach (k) -> place(k)

    # set locations for outer circle
    secondCircleKeys = keys.slice(firstCircleCount)

    # setup outer circle
    radius = radius + radius / 1.8
    increment = 360 / secondCircleKeys.length

    secondCircleKeys.forEach (k) -> place(k)

  # Gets a new location for input key
  place = (key) ->
    value = radialLocation(center, current, radius)
    values.set(key,value)
    current += increment
    value

  # Given an center point, angle, and radius length,
  # return a radial position for that angle
  radialLocation = (center, angle, radius) ->
    x = (center.x + radius * Math.cos(angle * Math.PI / 180))
    y = (center.y + radius * Math.sin(angle * Math.PI / 180))
    {"x":x,"y":y}

Hopefully the comments help walk you through the code. In setKeys our goal is to break up the total set of keys into an inner circle and an outer circle. We use slice to pull apart the array, after we figure out how many locations can fit in the inner circle.

radialLocation does the actual polar coordinate conversion to get a radial location. It is called from place, which is in turn called from setKeys.

Toggling Between Layouts

Lets the user explore different layouts interactively

With RadialPlacement in tow, we can now create a toggle between our force-directed layout and a new radial layout. The radial layout will use the song's artist field as keys so the nodes will be grouped by artist.

In the update function described above, we saw a mention of the radial layout:

 if layout == "radial"
      artists = sortedArtists(curNodesData, curLinksData)
      updateCenters(artists)

Here, sortedArtists provides an array of artist values sorted by either the number of songs each artist has, or the number of links. Let's focus on updateCenters, which deals with our radial layout:

  updateCenters = (artists) ->
    if layout == "radial"
      groupCenters = RadialPlacement().center({"x":width/2, "y":height / 2 - 100})
        .radius(300).increment(18).keys(artists)

We can see that we just pass our artists array to the RadialPlacement function. It calculates locations for all keys and stores them until we want to position our nodes.

Now we just need to work on this node positioning and move them towards their artist's location. To do this, we change the tick function for the D3 force instance to use radialTick when our radial layout is selected:

  # tick function for radial layout
  radialTick = (e) ->
    node.each(moveToRadialLayout(e.alpha))

    node
      .attr("cx", (d) -> d.x)
      .attr("cy", (d) -> d.y)

    if e.alpha < 0.03       force.stop()       updateLinks()   # Adjusts x/y for each node to   # push them towards appropriate location.   # Uses alpha to dampen effect over time.   moveToRadialLayout = (alpha) ->
    k = alpha * 0.1
    (d) ->
      centerNode = groupCenters(d.artist)
      d.x += (centerNode.x - d.x) * k
      d.y += (centerNode.y - d.y) * k

We can see that radialTick calls moveToRadialLayout which simply looks up the location for the node's artist location from the previously computed groupCenters. It then moves the node towards this center.

This movement is dampened by the alpha parameter of the force layout. alpha represents the cooling of the physics simulation as it reaches equilibrium. So it gets smaller as the animation continues. This dampening allows the nodes repel forces to impact the position of the nodes as it nears stopping – which means the nodes will be allowed to push away from each other and cause a nice looking clustering effect without node overlap.

We also use the alpha value inside radialTick to stop the simulation after it has cooled enough and to have an easy opportunity to redisplay the links.

Because the nodes are different sizes, we want them to have different levels of repelling force to push on each other with. Luckily, the force's charge function can itself take a function which will get the current node's data to calculate the charge. This means we can base the charge off of the node's radius, as we've stored it in the data:

charge = (node) -> -Math.pow(node.radius, 2.0) / 2

The specific ratio is just based on experimentation and tweaking. You are welcome to play around with what other effects you can come up with for charge.

Filter and Sort

Force-directed and Radial layouts after filtering for obscure songs

The filter and sort functionality works how you would expect: we check the networks current setting and perform operations on the nodes and links based on these settings. Let's look at the filter functionality that deals with popular and obscure songs, as it uses a bit of D3 array functionality:

  # Removes nodes from input array
  # based on current filter setting.
  # Returns array of nodes
  filterNodes = (allNodes) ->
    filteredNodes = allNodes
    if filter == "popular" or filter == "obscure"
      playcounts = allNodes.map((d) -> d.playcount).sort(d3.ascending)
      # get median value
      cutoff = d3.quantile(playcounts, 0.5)

      filteredNodes = allNodes.filter (n) ->
        if filter == "popular"
          n.playcount > cutoff
        else if filter == "obscure"
          n.playcount
    filteredNodes

filterNodes defaults to returning the entire node array. If popular or obscure is selected, it uses D3's quantile function to get the median value. Then it filters the node array based on this cutoff. I'm not sure if the median value of playcounts is a good indicator of the difference between 'popular' and 'obscure', but it gives us an excuse to use some of the nice data wrangling built into D3.

Bonus: Search

Search bar - Simple searching made easy

Search is a feature that is often needed in networks and other visualizations, but often lacking. Given a search term, one way to make a basic search that highlights the matched nodes would be:

  # Public function to update highlighted nodes
  # from search
  network.updateSearch = (searchTerm) ->
    searchRegEx = new RegExp(searchTerm.toLowerCase())
    node.each (d) ->
      element = d3.select(this)
      match = d.name.toLowerCase().search(searchRegEx)
      if searchTerm.length > 0 and match >= 0
        element.style("fill", "#F38630")
          .style("stroke-width", 2.0)
          .style("stroke", "#555")
        d.searched = true
      else
        d.searched = false
        element.style("fill", (d) -> nodeColors(d.artist))
          .style("stroke-width", 1.0)

We just create a regular expression out of the search, then compare it to the value in the nodes that we want to search on. If there is a match, we highlight the node. Nothing spectacular, but its a start to a must-have feature in network visualizations.

We can see that updateSearch is a public function, so how do we connect it to the UI on our network visualization code?

Wiring it Up

The other button groups use very similar code.There are a lot of ways we could connect our buttons and other UI to the network functionality. I've tried to keep things simple here and just have a separate section for each button group. Here is the layout toggling code:

  d3.selectAll("#layouts a").on "click", (d) ->
    newLayout = d3.select(this).attr("id")
    activate("layouts", newLayout)
    myNetwork.toggleLayout(newLayout)

So we simply active the clicked button and then call into the network closure to switch layouts. The activate function just adds the active class to the right button.

Our search is pretty similar:

  $("#search").keyup () ->
    searchTerm = $(this).val()
    myNetwork.updateSearch(searchTerm)

It just uses jQuery to watch for a key-up event, then re-runs the updateSearch function.

Thanks and Goodnight

Hopefully we have hit all the highlights of this visualization. Interactive networks are a powerful visual, and this code should serve as a jumping off point for your own amazing network visualizations.

Other placement functions could be easily developed for more interesting layouts, like spirals, sunflowers, or grids. Filtering and sorting could be extended in any number of ways to get more insight into your particular dataset. Finally, labelling could be added to each node to see what is present without mousing over.

I hope you enjoyed this walk-through, and I can't wait to see your own networks!
